DW-8602
Availability: | |
---|---|
Wide operating temperature with every point setting
Precise temperature control, Inner temperature fluctuation within ±1℃
At the 25℃ ambient temperature. Very High Efficiency
Very flexibility, You can bring it to anywhere you want
Low Vibration and Noise
Use 99.999% Helium refrigerant and R-170 Cooling Conduction liquid
Cooling Chart
Portable Ultra Low Temperature Freezer | |||
Type | DW-8602 | ||
Storage Volume | 2L | ||
Electric Power | 100V AC to 240V AC;50Hz,60Hz; 12V DC to 24V DC | ||
Maximum Power (Current) | 100W (0.5A@220V,4.6A@24V) | ||
Cooling Engine | Free-piston Stirling Cooler | ||
Refrigerant | Helium (He) | ||
Heat Transport System | Gravity driven thermosiphon | ||
Temperature Range | 18℃ to -120℃ | ||
Environmental Conditions | Non-corrosive, Non-flammable,Non-explosive,Altitude up to 2000m | ||
Temperature 5℃ to 35℃, maximum relative humidity 80% | |||
Performance Data | Ambient temperature is 25℃; Empty Cabinet | ||
Take 2 hours from 25℃ to -120℃ | |||
Steady State Energy | Ambient temperature is 25℃ | ||
65W | |||
Insulation | High performance vacuum insulated panels, polyurethane foam | ||
Noise | <55dB | ||
Control Sensor | One RTD(PT100 Class B),precision±0.3 | ||
Security | Lockable lid | ||
Warm and cold alarms | Setpoint ±10℃ | ||
Defrost Method | Manual | ||
Certification | CE/EMC、CE/LVD、CQC | ||
Interior(LxWxD) | 160*160*80mm | ||
Exterior(LxWxD) | 245*245*450mm | ||
Net Weight, Empty | 11KG | ||
Shipping(LxWxD) | 390*400*550mm | ||
Shipping Weight | 16KG |
Scientific Research:
For equipment requiring ultra-low temperature environments, such as low-temperature physics experiments and superconductivity research.
Medical:
For low-temperature storage of biological samples, vaccines, and pharmaceuticals.
Space Exploration:
For cooling systems in satellites, spacecraft, and space stations.
Industrial:
For manufacturing and processing that require precise temperature control, such as cooling electronic components and processing special materials.
